2027 LBT 9,500 Gallon DOT 406 Aluminum Fuel Tank Trailer – 4 Compartment, Double Taper
New 2027 LBT 9,500 gallon DOT 406 aluminum fuel tank trailer available and built for gasoline and fuel oil transport. This 4-compartment double taper petroleum trailer is rack-ready and equipped with a Civacon Blue Diamond bottom load and vapor recovery system, Hendrickson Intraax air ride with lift axle, and air disc brakes with ABS and roll stability.
Ideal for fuel distributors, petroleum carriers, and fleet operators looking for a late-model DOT 406 tanker trailer with premium components and full compliance. Key Specifications Year: 2027 Manufacturer: LBT Capacity: 9,500 gallons (+3%) DOT Rating: DOT 406 (up to 7.5 lb/gal) Compartments: (4) – 3,500 / 2,000 / 1,200 // 2,800 gallons Commodity: Gasoline, Fuel Oil Tank Design: Elliptical double taper, baffled, dished heads Material: 5454 aluminum shell, heads, and baffles Chassis & Suspension Aluminum straight-channel chassis (Huck-bolted) (2) Hendrickson Intraax air ride suspensions Front lift axle with Wabco InfoLink automatic & manual control Hendrickson MAXX22T air disc brakes ABS with Roll Stability Support (RSS) Aluminum wheels with 11R22.5 radial tires Jost AX150 aluminum landing gear Fuel System & Bottom Load Civacon Blue Diamond fuel system – 5-year warranty Civacon MaxAir II internal emergency valves (each compartment) API openable bottom loading adapters Gravity off-loading couplers Sight glasses at each discharge Overfill, Safety & Compliance Civacon ROMLink Plug-N-Load overfill prevention system Optic top sensors and retain sensors in all compartments VIP electronic ID module Additional Features Full-length curbside aluminum hose trough Aluminum fitting cabinet with shelving Cone and bucket holder Rear ladder with Safety Walk non-skid walkway Calibration charts included Why This Trailer New LBT DOT 406 fuel tanker with industry leading 3-Year Warranty High-spec petroleum trailer with air disc brakes Lift axle for weight optimization Rack-ready with full vapor recovery and overfill protection Ideal for gasoline, diesel, and fuel oil delivery operations 📞 Call for pricing, availability, or delivery options nationwide.
